An electrically controlled switch used to switch an electrical power circuit is called a contactor. A circuit that has significantly less power than the switched circuit is frequently used to control a contactor, such as a 24-volt coil electromagnet controlling a 230-volt motor switch.
Capacitors are intended to be directly linked to high-current load devices, in contrast to general-purpose relays. Relays are typically built for both ordinarily closed and normally open applications and have a lesser capacity. Contactors are often devices that switch more than 15 amperes or in circuits rated more than a few kilowatts. Contactors are nearly solely equipped with typically open (“form A”) contacts, with the exception of optional auxiliary low-current contacts.
There are numerous different types of contactors with various characteristics and capacities. A contactor is not designed to stop a short circuit current, in contrast to a circuit breaker. The breaking current range for contactors is from several amperes to thousands of amperes, and from 24 V DC to many kilovolts.
Contactors can be as small as something you can hold in one hand or as enormous as something that’s about a yard (meter) wide. Electric motors, lights, heating, capacitor banks, thermal evaporators, and other electrical loads are all controlled by contactors.
There are three parts to a contactor. The component of the contactor that carries current is the contacts. Power contacts, auxiliary contacts, and contact springs are all included in this. High electrical conductivity, mechanical toughness, and stability during arcing and oxidation are all considered while selecting contact materials. Metal alloys made of tungsten, molybdenum, copper, and other elements are frequently utilized.
When electrical switches are opened and closed, an electronic circuit called a switched capacitor (SC) moves charges into and out of capacitors to carry out a function. In order to prevent all switches from closing at once, non-overlapping clock signals are typically employed to regulate the switches.
Switched-capacitor filters are those that employ these components and rely solely on the ratios between capacitances and the switching frequency rather than precise resistor values. Due to the high cost of manufacturing precisely specified resistors and capacitor switching contactors, they are considerably more suitable for usage in integrated circuits.
The Global Capacitor Switching Contactors market accounted for $XX Billion in 2023 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2024 to 2030.
Launched by ABB, the UA30.RA 3-pole capacitor switching contactors are suitable for applications where the peak current is much greater than 100 times the normal RMS current. The contractors must be used without any additional inductances and are delivered complete with their dampening resistors.
When the contractors are made, the capacitors must first be drained (maximum residual voltage at terminals 50 V) before being re-energized. For UE 500 V, their electrical durability is 2,50,000 working cycles, and for UE 500 V to 690 V, it is 100,000 operating cycles.
The UA.RA contractors are equipped with a unique front-mounted block that makes sure that three dampening resistors are serially inserted into the circuit to reduce the peak current during the energization of the capacitor bank.
Additionally, their connection guarantees that the capacitors are pre-charged in order to reduce the second current peak that occurs after the main poles are made. The addition of resistors enables the capacitor’s greatest current peak, regardless of its level, to be reduced. The 3-pole contactors in the UA.RA series are block-style devices.
