A piece of electronic test gear or software called a digital pattern generator produces stimulus for digital electronics.
A specific type of electrical waveform that alternates between two conventional voltages that represent two logic states is referred to as a digital electronics stimulus (“low state” and “high state”, “0” and “1”).
A digital pattern generator’s primary function is to stimulate an electronic device’s inputs. Because of this, the voltage levels produced by a digital pattern generator are frequently compatible with the I/O standards for digital electronics, such as TTL, LVTTL, LVCMOS, and LVDS.
The Global Digital Pattern Generators market accounted for $XX Billion in 2021 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2022 to 2030.
A 64-channel digital pattern generator and recorder, the DP-cPCI-3996 is made by Digital Patterns. For pattern generator, recorder, direction, and control, each channel includes a 16Kbit deep pattern memory that is independently accessible.
Both pattern generation and pattern recording can be done using the pattern memory. A maximum clock speed of 15MHz can be used for pattern generation or recording.
The 64 channels have been divided into 4 groups, each with 16 channels. Each group can be set up to either create patterns or record patterns.
64 channel digital pattern generation and recording, 64x16K deep pattern memory that is individually available for the generator, recorder, direction, and control, and 15MHz pattern generation are some of the important features.
Features of segmentable pattern memory – Start and Repeat pattern stores – Triggered pattern generation, recording, and post-processing – Repeat pattern repeating continuously or up to 64K times,
four clusters of sixteen channels each, for external synchronisation, configurable polarity pacer and trigger output, group-specific features – Internal or external pacer – One of the chosen groups may be an external pacer.
– A 32-bit counter for frequency control – Group synchronisation – The generation/recording mode selected group, a single 6U cPCI slot, Windows 2000 drivers, and RT Linux drivers are all included.
