An electrode is a conductor that establishes electrical contact with nonmetallic circuit components such an electrolyte, a semiconductor, or a vacuum. This can also be referred to as an anode or a cathode if it is in an electrochemical cell.
Oxidation takes place at the anode, an electrode where electrons exit the cell. Through the cathode, where a reduction process takes place, electrons enter the cell.
Because it can function as either a cathode or an anode, depending on the direction of the electron flow, an electrode cannot be fixed permanently.
In businesses and factories, the word “handling” has great significance. The factories are where the primary production components of enterprises are made.
Therefore, the entire company would suffer a big loss if any problems arise during the manufacturing or distribution process. You can never underestimate how important the materials handling process is as a factory owner or product provider.
There are numerous pieces of technology and software available nowadays that greatly simplify the handling procedure. These tools make it easier for you to move, store, control, and secure products and goods till disposal. These tools are unquestionably crucial for the entire product handling procedure.
The Global Electrode Handling Equipment market accounted for $XX Billion in 2021 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2022 to 2030.
Robotic electrode handling in tankhouses was pioneered by ISAKIDD, considerably increasing productivity and streamlining handling procedures. Robotic cathode stripping was successful utilizing the same technology that was used for copper stripping activities in electro-winning and electro-refining.
Engineers at ISAKIDD came to the conclusion that, in order to boost stripping rates with current technologies, it was necessary to design the procedure to accommodate the “rare” problematic cathode that created a stripping restriction for mechanical stripping equipment.
Robotic stripping machines, which can be configured to suit the numerous and diverse types of copper cathode that can be produced in tankhouse operations, have, however, overcome this constraint.
With the use of unique stripping mechanisms, ISAKIDD engineers have further optimized the stripping procedure, enabling effective, fast stripping operations.
Our semi-automatic cathode stripping machine uses hydraulic, pneumatic, and electrical control systems to construct operations both automatically and manually. All of the following are offered: receiving, washing, pivot transferring, flexing and chiseling, stacking, discharging, and rejection.
The No-Touch Electrode Handling System, created by engineers at Contractors & Industrial Supply, Inc. (CIS), is unique among products available today. This exceptional automated system is the pinnacle of security and effectiveness, with seven patents protecting its essential components.
No operator is ever put in danger thanks to the patented No-Touch Electrode Addition System, which was specifically designed to meet the special requirements and safety challenges of the steel industry. The made-to-order No-Touch products have internal gripping teeth and locking mechanisms that stop the column from rotating during crucial steps in the joining process.
To deposit used electrode columns, suspend and add new columns by setting the gap, and then automatically spin down a new electrode and torque it to the manufacturer’s recommendations, the operator merely uses a set of control levers.
The electrode equipment from Metso Outotec provides a full system for moving and slipping the electrodes as well as transferring electrical power to the smelting process. A mantle connects the upper assembly and lower assembly that make up the electrode column.
A slipping mechanism, primary regulation cylinders to control electrode movement, and paste heaters make up the upper portion. A fail-safe spring clamping system with an adjustable spring force serves as the slipping device. The slipping device’s design makes maintenance simple and uses fewer spare parts.
According to the fail-safe design principle, the hydraulic system was created. The PLC’s software and programming are also supplied by Outotec. The plant automation system includes the electrode controls. To prevent any arcing, all equipment is electrically insulated.
China’s Systems for Handling and Cleaning Carbon Electrodes A high-tech business that produces automation equipment and offers turn-key projects for the cold chain, automotive, and electronics industries is Dalian BeiMeng Technology Co., Ltd. Several domestic leading carbon companies, including Fangda Carbon, Dongfang Carbon, and Wanji Holding group, have used their electrode cleaning equipment.
Mazzella CIS has revolutionised safe and effective electrode handling operations across the steel industry with its patented No-Touch Electrode Addition System.
The purpose of the electrode recovery tong is to recover broken electrode columns or sections. This device has a Heppenstall latch and can hold the electrode in any orientation, from true horizontal to slightly vertical.
Electrodes can be transported vertically to and from the furnace using graphite lift plugs. These gadgets give the operator the option of leaving the gadget on the column while the furnace is running.
