Global Electron Backscatter Diffraction (EBSD) Analysis System Market
INTRODUCTION
EBSD is a method for characterising materials that is based on scanning electron microscopy (SEM). In EBSD, the surface of a slanted crystalline sample is covered with an electron beam that is scanned across it.
The diffracted electrons at each point create a pattern that can be recognised and then examined with the use of specialised hardware and software. The indexing procedure offers details regarding the phase and crystallographic orientation at each point, allowing for an efficient reconstruction of the microstructure.
This makes it possible to fully characterise the sample’s microstructural characteristics. Phase fractions, grain structures, boundary populations, strain distribution, and crystallographic texture are just a few of the microstructural details that may be obtained with the incredibly versatile EBSD technology.
In EBSD, an electron beam that is stationary interacts with a crystalline sample that is tilted, and the diffracted electrons create a pattern that can be seen on a fluorescent screen.
A technique based on the scanning electron microscope (SEM) called electron backscatter diffraction (EBSD) allows for the analysis, visualisation, and quantification of a sample’s microstructure.
The interior structure of a material is known as its microstructure and is studied at the microscopic level. Because a material’s intrinsic characteristics (or structure) will affect its properties and behaviour, it is interesting.
The definition of “microstructure” comprises identifying and describing grain populations, examining the various phases or compounds present in the substance, describing the spatial distribution of elements, and examining the types of grain-to-grain interactions.
GLOBAL ELECTRON BACKSCATTER DIFFRACTION (EBSD) ANALYSIS SYSTEM MARKET SIZE AND FORECAST
The Global Electron Backscatter Diffraction (EBSD) Analysis System Market accounted for $XX Billion in 2022 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2023 to 2030.
RECENT DEVELOPMENT
A scanning electron microscope (SEM) technique called electron backscatter diffraction (EBSD) is used to examine the crystallographic structure of materials. A scanning electron microscope that is fitted with an EBSD detector that includes at least a phosphorescent screen, a compact lens, and a low-light camera is used to perform EBSD.
The slanted sample is struck by the SEM incident beam in this setup. Backscattered electrons interact with the periodic atomic lattice planes of the crystal as they leave the sample and diffract in accordance with Bragg’s law at different scattering angles before reaching the phosphor screen to create Kikuchi patterns (EBSPs).
The type of the material being studied and the sample preparation are just two of the many variables that affect EBSD spatial resolution. As a result, EBSPs can be indexed to offer details about the material’s microscale grain structure, grain orientation, and phase. Impurities and defect investigations, as well as plastic deformation, are studied using EBSD.
Overall, EBSD is a flexible and effective approach that may offer insightful information about the microstructure and characteristics of a variety of materials. EBSD is a vital technique for creating novel materials and comprehending how they behave in various environments. It is frequently used in materials science and engineering.
Electron backscatter patterns (EBSPs) deterioration and change reveal the lattice deformation in the diffracting volume. Pattern degradation (i.e., diffuse quality) can be used to determine the extent of plasticity. The residual elastic stress and tiny lattice rotations can be measured by changing the position of the EBSP zone axis. Geometrically required dislocations (GND) density can be determined using EBSD.
