Horizontal and vertical machining centres, inspection, part cleaning, pallet loaders, and operators are all connected via an automated material handling system. With minimal to no user involvement, a robot transport installed on a floor track unit transfers material to and from equipment.
No matter how big or small your manufacturing operation may be, fixture plates can be a crucial component. Fixture plates, sometimes referred to as tooling plates, are offered in a modular arrangement.
During the production process, pieces are held in place by fixture plates. Typically, aluminium is used to build them. Aluminum fixture plates are straightforward, inexpensive products that are frequently fabricated to order for a particular operation and then promptly discarded.
However, fixture plates made of steel and cast iron are frequently used for extended periods of time. Utilizing CNC machining technology, fixture plates may frequently be produced quickly and in large quantities.
The numerous threaded holes in fixture plates let them to hold items while they are being manufactured. Typically, screws are placed into these holes to protect them. When the holes must be used, these screws can be removed.
Global fixture plate handling system market accounted for $XX Billion in 2022 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2023 to 2030.
At IMTS 2022, Metrology Works will introduce its new line of Coordinate Measuring Machine (CMM) fixture plates and related rail system (booth 135730).
Any CMM or manufacturing system may be quickly loaded with parts and plates thanks to the MegaLok fixture plates. Aluminum tooling plate grade is used to make the MegaLok fixture plates, which are then hard coat anodized in black for durability.
Measurement Works A Metrology Works-specified XLF coating is also included on MegaLok CMM fixture plates to boost abrasion resistance and reduce friction.
To produce the most adaptable docking system in the sector, the Metrology Works Lightning rail system design has a moveable hard stop.
The stainless steel rail, a first for the industry, provides more docking spots than are currently available. Keystones make it simple and quick to join MegaLok plates together.
MegaLok plates are made to be stacked several broad in order to completely fill the table and completely cover a machine work area. Even from a single docking site, the keystone design will enable users to create L or T configurations of plates.
