The Mini PCI card that is found on many Mini-ITX mainboards can be replaced with the PCIe Mini Card. It is 30 mm x 51 mm, or half the size of a Mini PCI card.
In contrast to the 100-pin stacking connector of Mini PCI Type I and II cards and the 124-pin edge connector of Mini PCI Type III cards, it has a 52-pin edge connector.
The Global PCI Express Mini Cards market accounted for $XX Billion in 2021 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2022 to 2030.
ACCES I/O Products, Inc. is pleased to announce the availability of the mPCIe-DIO Family with Digital Integration Features, a brand-new collection of mini PCI Express (mPCIe) digital I/O cards.
For compact control and monitoring applications, these small, low-cost PCI Express Mini cards offer a vast array of digital I/O functions.
You can select from up to 24 channels with varying options for voltage, isolation, speed, and counter/timer. Add more I/O functions to systems without having to modify or customize the boards.
System integrators have access to a wide range of ready-made I/O configurations for both new and existing embedded systems thanks to this highly adaptable and effective design.
For reducing shock and vibration, all ACCES mPCIe cards have latching connectors with high retention and an extended operating temperature range of -40°C to +85°C.
The cards were made to be used in harsh and rugged environments like the military and defense, as well as in health and medical, point of sale, kiosk design, retail, hospitality, automation, gaming, and other applications.
The compact size (50.95 x 30 mm) makes it possible to achieve maximum performance in applications where space is at a premium.
