Shear beam load cells are commonly utilized when operators need to measure compressive forces. A spring element is the primary component of a shear beam load cell.
This element is a piece of metal that is elastically deformed under load and recovers when the load is removed. A load cell is an electromechanical sensor that measures force or weight.
Shear beams are intended for static and dynamic measurements in both tension and compression directions. They calculate shear forces in a variety of applications.
These shear beams are employed in industrial weighing, laboratories, and the process sector.
The Global Shear Beam Load Cells market accounted for $XX Billion in 2023 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2024 to 2030.
Shear Beam Load Cells Thames Side’s shear beam load cells have some of the best specifications on the market for process weighing, industrial scale, and general measurement applications.
They are specifically developed for high accuracy applications such as tank and vessel weighing, filling systems, platform scales, bagging machinery, belt scales, and conveyor systems.
Their Type T85 and T85-T are made of stainless steel, are fully welded, and are hermetically sealed to give complete environmental protection (IP68 and IP69K). The T85-T variant includes a blind loading hole, making it perfect for use in platform scales.
For less severe situations, our T85-N nickel plated alloy steel shear beam is built with a humidity-resistant silicone potting solution.
Their shear beam load cells have Weights and Measures clearance from OIML as well as Model approval from the Legal Metrology Department of the Government of India.
The T85 load cell series has OIML C3 (3000 divisions) approval. The T85 has ATEX and PESO clearance for usage in hazardous locations.
There is no need for safety barriers in dust zones 20, 21, and 22. Special cable lengths, Parylene coating (for very hostile and corrosive environments), high temperature versions, as well as your own company labelling and 3rd party OIML certification, are all available.
