Planetary gears, clutches, brakes, a hydraulic pump, and a torque converter are some of the more important components of an automatic transmission.
The hydraulic pump and transmission input shaft get engine power through the torque converter.
The planetary gears are arranged in a succession, one after the other. a device that accurately measures distances using mechanical or optical means on standards of length, gauges, and other parts, often with an accuracy of at least 0.0001 inch.
The Global Transmission parts measuring machine market accounted for $XX Billion in 2023 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2024 to 2030.
automotive transmission parts measured precisely The production of more parts more quickly without sacrificing precision is a challenge for the automotive industry.
Quality technicians and engineers need to be certain that their measurement results are extremely accurate when faced with the special measurement problems that come with transmission gear components.
High accuracy measurements are possible with the GLOBAL S coordinate measuring machine (CMM) from Hexagon Manufacturing Intelligence thanks to the Precision capabilities package, which also gives users more visibility into the environment around the CMM.
Transmission gear component examination is specifically required by gear manufacturers.
The helical gear, for instance, operates much more smoothly and quietly because of its inclined form.
This tilted structure necessitates exact measuring of the gear’s teeth.
It was intended for the GLOBAL S CMM to deliver extremely accurate measurements. Due to its excellent strength-to-weight ratio, aluminium is the perfect material for creating incredibly stiff yet light constructions.
The TRICISION beam gives the optimal stiffness-to-mass ratio of the bridge and, consequently, great accuracy and long-term stability, while the precision-machined dovetail guideways provide perfect guiding along the full travel path of the machine.
Advanced geometric compensation methods are used by GLOBAL S CMMs to obtain the best accuracy.
The revolutionary Compass technology of the CMM’s elastic joints and sophisticated firmware algorithms are able to absorb the vibrations produced during high-speed scanning measurements, guaranteeing the machine remains incredibly exact.
