Double Flank gear rolling test is generally included in final acceptance test. A gear tested on Double Flank Gear Tester is normally the indication of good running properties of the gear and is adequate assurance about the quality of gear.
The readings taken are the validation of center distance between two gears to be inspected or between one gear and one master gear meshing without backlash during one complete rotation of gear.
Global CNC double flank gear rolling tester market accounted for $XX Billion in 2022 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2023 to 2030.
CNC DOUBLE FLANK GEAR ROLLING TESTER TF-40 & TF-66R.
The TF-40NC is designed to test the mesh of small gears accurately and efficiently, which are used in almost every industry such as clocks, cameras, compact machine tools and electronic equipment.The TF-40NC has dramatically improved stability, work efficiency, and measurement accuracy with its world’s first CNC double flank gear rolling testing mechanism.FEATURES:Tester, calibrated by automatic calibration function, does not need to be re-adjusted for zero-point before each measurement.The size management program displays the average, minimum centre distance and maximum center distance.Automatically compensates for the runout of the master gear.
GTR-4 is a double flank gear rolling tester for fine pitch gear or small gear used for the wide range of instruments such as measuring equipment, clock, camera, computer peripheral equipment, copying machine and audio device all over the world.
Connecting PC with a double flank gear rolling tester, GTR-4, GTRT-30 and GTR-40, GTR-PC can output the calculating results of composite errors and runout in both analog and digital and judge the grade of JGMA or AGMA.
GTR-4 is a double flank gear rolling tester for fine pitch gear or small gear used for the wide range of instrument such as measuring equipment, clock, camera, computer peripheral equipment, copying machine and audio device all over the world.
