Investigations are made on the thermal-mechanical stability of flip chip on board (FCOB) with copper pillar solder joints.
The intermetallic compound (IMC) serves as the primary body of the copper pillar solder joint, which is produced by lengthening the thermal compression bonding (TCB) process’s time and temperature parameters.
The thermal cycling test is then performed independently on the joint structures of the Copper Pillar Flip Chipand the Cu pillar/IMC/Cu pad.
The Sn-Ag solder joint has been seen to shatter due to ductile fracture, which is accompanied by fatigue and then extension through microvoids brought on by creep.
And the brittle fracture along the Copper Pillar Flip Chip and Cu3Sn phase interface is what is mostly to blame for the IMC joint break.
Two life prediction models that are simultaneously constitutive of viscoplasticity, elastic-plastic-creep.
The Global Copper Pillar Flip Chip market accounted for $XX Billion in 2022 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2024 to 2030.
A common type of flip chip interface that gives benefits in many designs while satisfying present and future ROHS regulations is Copper Pillar Flip Chip.
For applications requiring a blend of fine pitch, ROHS/Green compliance, low cost, and electro migration performance, such as transceivers, embedded processors, application processors, power management, baseband, ASICs, and SOCs, it is a great connectivity option.
Down to 30 m in-line and 30/60 m staggered fine pitch capability.superior electromigration performance for applications requiring large current carrying capacities.
Electrical check before Copper Pillar Flip Chip bump at wafer level.Compatible with wire bond die’s bond pad opening/pitch and pad metallization, allowing speedy time-to-market for flip chip conversion.
By lowering substrate layer counts, cost reduction is possible in many designs.For high bump density designs, fine pitch flip chip (FPFC) connection is less expensive than Au stud bump.
There are several types of copper pillar constructions available, including micro-bumps, regular Copper Pillar Flip Chip , and copper bars.
Additionally, depending on the needs of the application, multiple stack-ups are possible, including Cu+Ni+Pb-free and Cu+Ni+Cu+Pb-free.offered both with and without repassivation advanced silicon node qualified Low-k gadgets,little fillet needed.
