These dual voltage supply, bi-directional voltage translators employ direction control. Some categories are eligible for bus holds. Conformity (only the automotive industry supports PPAP) They can be used to convert voltages, either from a higher input voltage to a lower output voltage or from a lower input voltage to a higher output voltage.
The ALVC, AVC, and LVC device families contain these gadgets, which have low power consumption.A unidirectional signal is translated up or down by direction-controlled voltage translators without inverting it. The designer can configure which pins are inputs and outputs using one or more direction control pins that are present in these.
The Global Direction controlled Voltage Translator market accounted for $XX Billion in 2022 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2023 to 2030.
A new member of Diodes Incorporated’s family of low voltage level translators, allowing straightforward and independent bidirectional operation, was announced today.
The PI4GTL2002 is a 2-bit level shifter that can convert signals like gunner transceiver logic (GTL) or GTL+ to LVTTL/TTL that are conditioned for one voltage level to signals at a higher or lower voltage.
High performance level translators are becoming more necessary in applications like server/data centres and networking as top processor manufacturers keep including GTL+ interfaces in their devices.
With the extra bonus of not requiring directional control, the PI4GTL2002 satisfies that need.A unidirectional signal is translated up or down by direction-controlled voltage translators without inverting it.
The designer can configure which pins are inputs and outputs using one or more direction control pins that are present in these.Dual supply level translator devices are one choice for voltage level translation.
These gadgets enable voltage level translation in both directions. They can be used to convert voltages, either from a higher input voltage to a lower output voltage or from a lower input voltage to a higher output voltage.
With reference voltages for the two signals, the NMOS-based pass transistors in the design enable bidirectional operation via a common gate. This allows for voltage translation between signals ranging from 0.8V to 5V and allows the design team to apply a distinct voltage to either side of the device.
The PI4GTL2002’s pin-out utilises a practical flow-through design, simplifying PCB layout.
