A DC-DC converter is a necessary component in electric cars with several electrical circuits running at different voltage levels.The DC-DC converter is an electromechanical device or circuitry that converts a direct current voltage from one level to another dependent on the needs of the circuit.
The DC-DC converter is a type of electric power converter that may be used for low voltage applications such as batteries or high voltage applications such as HV power transmission.When there were no semiconductors, a typical way for transforming DC voltage into greater voltage for low-power tasks was to use vibrator circuits.
The output voltage level was then increased using a step-up transformer, followed by a rectifier circuit to achieve the DC conversion. For applications requiring high power, a combination of motor and generator was used.
The generator is powered by the motor, which provides the appropriate load voltage. These approaches were costly and inefficient, yet they were adopted since no other option existed at the time.
The development of power semiconductors and integrated circuits (ICs) resulted in a variety of less expensive options, such as DC power supplies, which use high-frequency AC to power a transformer. This gadget is less costly and simpler to use. It modulates the voltage, which is then converted to direct current using rectifiers.
The switching approach is often employed in converter functioning. The output voltage of a switched-operated DC-DC converter might be greater or lower than the input voltage depending on the application requirements. During conversion, the converter stores energy for a period of time and produces output at various levels.
The energy is stored in the form of a magnetic field in conductor transformers and an electrical field in capacitors. Switching voltage conversion is simpler and more energy efficient than linear voltage conversion, which wastes electricity as heat.
To achieve efficiency, high-speed semiconductor devices with short rise and fall periods are required. High-speed switching necessitates precise layout, making circuit design complex. The switched-mode converter’s great efficiency eliminates the requirement for heat sinks and extends battery life.
Using FETs improves converter efficiency since they conduct the switching operation more effectively and with less losses than BJTs.
Using FETs improves converter efficiency since they conduct the switching operation more effectively and with less losses than BJTs.Other enhancements to the DC-DC converter include the replacement of the flyback diode with synchronous rectifier circuit with a power FET, which has less resistance and reduces switching losses.
The majority of DC-DC converters are intended to control power flow in just one way, from input to output. All switching regulator circuits, on the other hand, can be bidirectional and transmit power in either way.
Bidirectional converters are useful for applications such as vehicle regenerative braking, in which power is sent to the wheels during driving and received during stopping.
DC-DC converters, like any high-frequency circuits, require some precautions, such as component selection, connections, and an acceptable amount of switching noise. The cost of development was initially higher than that of linear regulators, but it eventually lowered due to the use of the most recent circuit building technology.
DC-DC converters are now based on integrated circuits and require a few extra components. They also exist in a hybrid arrangement, which is employed in a variety of electrical structures.
Many various types of cars moving around us contribute to air pollution, global warming, and resource depletion. To address these difficulties, replacing conventional automobiles with EVs, Hybrid vehicles, and fuel-cell electric vehicles is one possibility. Two types of energy storage devices are used in electric and hybrid cars.
The first is MES (Multi-Function Energy Storage), which is used to store large amounts of energy, and the second is a rechargeable energy storage system (RESS), which gives high power capability as well as reversibility. MES offers a long driving range, whereas RESS has an excellent regenerative braking and accelerating system.
The output voltage of an energy storage device varies with load, and the high voltage of the DC connection causes issues for vehicle engineers when configuring energy storage components.
The Global EV DC-DC Converter Market accounted for $XX Billion in 2023 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2024 to 2030.
BrightLoop Converter’s new DCHV MP DC DC converter aims to give the greatest off-the-shelf DC DC conversion solution to fuel cell cars by concentrating on exceptional power density and modularity.
The fuel cell in a Fuel Cell Electric Vehicle (FCEV) generates electricity to power the high-voltage batteries that power the electric motor. However, fuel cells do not produce a constant voltage: it changes depending on the kind and quantity of cells used, as well as their operating circumstances.
Furthermore, in order to speed the use of hydrogen in electric mobility applications, fuel cell systems must be adaptable to existing electric architectures without the need to construct a full specialized powertrain. As a result, the DC DC converter is an essential component.
BrightLoop Converters introduces the DCHV MP, a new standard HV->HV DC DC converter designed to interact with fuel cells at all power levels. BrightLoop Converters, like its current product lines, provides the DCHV MP as an ultra size and weight optimized converter with an extreme level of adaptability.
The DCHV MP is completely reversible, may work in either buck or boost mode, and several converters can be paralleled to suit the demands of greater power fuel cells.
The DCHV MP is the first product in a new series that will include greater and lower current ratings, buck-boost designs for overlapping input and output voltage ranges, and galvanic isolation.
BrightLoop Converters also has a selection of lower voltage converters that are precisely optimized for fuel cell applications and include the following features:
Optimized for low-voltage operation, including reversible current operation and fuel cell current management, buck-boost architecture for overlapping input-output voltage, best-in-class power density, remote communication and monitoring, and more.
