A single-phase synchronous motor with a magnetic hysteresis operating mechanism is known as a hysteresis motor. The magnetic flux density in a ferromagnetic material lags behind the magnetising force, according to magnetic hysteresis.
The following are the properties of a hysteresis motor: Hysteresis motors have uniform torque from zero to synchronous speed. No matter how much inertia a load has, a hysteresis motor can synchronise any load that it can accelerate.
A hysteresis motor rotates the load smoothly and is intrinsically quiet. The number of rotor poles and stator poles in a hysteresis motor are equal.
A range of synchronous motor speeds can be achieved by varying the number of stator poles using pole-changing connections. A hysteresis motor behaves similarly to a single phase induction motor while starting, and similarly to a synchronous motor when operating.
In the operating principle, its behaviour can be accomplished gradually The stator generates a revolving magnetic field when it is powered by a single phase AC supply.
The primary and auxiliary windings need to be continually supplied both during startup and operation in order to sustain the spinning magnetic field.
Secondary voltage is induced in the rotor at startup due to the induction phenomena caused by the revolving magnetic field of the stator. In order for eddy current to flow in the rotor and develop the rotor, it must be generated.
The Global Hysteresis Motor market accounted for $XX Billion in 2022 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2023 to 2030.
TAKCHUAN launch a Good Quality AC Hysteresis Motor 220V 5-6RPM 5W from them is a reliable name in Specifications for the item Pear-shaped, 2-hole-mount SD-204 motor with a speed range of 1 to 6 RPM. It has the ability to perpetually halt and spring back. Quiet and smooth are some of the product’s features.
capabilities, return of spring. lengthy life. Steel and brass gears make up the gear train. Information about the product The motor’s power ranges from 3 to 10 Watts, and the various gear sets affect the motor’s direction.
For information, please contact the sales department. Rated Voltage (AC): 24, 120, and 220/240 V. Fidelity: 50/60 Hz 5W is the power consumption. 1/6 RPM is the motor speed. 1RPM: 320 Kgf-cm of torque
