The detection of physical characteristics, whether discrete or continuous, is an essential component of a mechatronics system.
A sensor is described as “a device which gives an useful output in response to a specified measure” in the Electrical Transducer Nomenclature and Terminology standard.
The capacitive-type sensor is one of the most often used sensors in mechatronic systems.
With the displacement of a diaphragm in a pressure sensor, the linear or rotational motion of an item relative to the reference, or the displacement of vibration sensors, capacitance varies nonlinearly.
This sensor’s linearization and calibration have been the subject of much investigation.
The Global Mechatronics sensors market accounted for $XX Billion in 2022 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2023 to 2030.
To provide optical picture stabilisation, Cambridge Mechatronics launched the SMA sensor shift actuator (OIS).
The need for optical image stabilisation (OIS) has never been more critical given that smartphone cameras are incorporating many of the characteristics of cutting-edge digital stills cameras, promising Hollywood-calibre movie creation.
The image sensor can be moved using a technology called sensor shift OIS in response to a smartphone handshake motion.
The use of bulky lenses with variable apertures is possible by moving the image sensor rather than the lens. As a result, 5-axis stabilisation is now possible, which was not possible with lens shift IS.
The requirement to relocate the image sensor while concurrently connecting it to the handset presents the fundamental challenge in sensor shift.
The force that can be generated by conventional voice coil motor (VCM) actuators, which utilise magnets and electromagnetic coils, is constrained.
Components and assembly procedures, as well as the necessity of moving the image sensor and connection, which enlarges the camera footprint and bump-out size, are further VCM restrictions.
Roll, the fifth axis of motion, is also not supported by VCM designs because it is against one smartphone brand’s patent portfolio, which restricts usage to a larger market.
The actuator is made of four 25 um diameter SMA wires arranged in a square pattern around the image sensor.
