MONOLAYER GRAPHENE FILM MARKET

INTRODUCTION TOMONOLAYER GRAPHENE FILM MARKET

 Carbon atoms are organised in a hexagonal honeycomb lattice to form the atomically thin layer that makes up graphene monolayer film. The Scotch-tape method of mechanical exfoliation was used to isolate it first.

Later discovered alternate techniques for producing high-quality single, bilayer, and few-layer graphene films include chemical vapour deposition (CVD) and epitaxial techniques.

Nanomaterials based on graphene have uses in the production and storage of energy due to their special mix of innovative electrical, optical, and mechanical properties. They can be used in biomedical applications, photovoltaic devices and batteries, sensors and flexible electronics, and photodetectors, for instance.

MONOLAYER GRAPHENE FILM MARKET SIZE AND FORECAST

 The Global Monolayer Graphene Film market accounted for $XX Billion in 2023 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2024 to 2030.

MONOLAYER GRAPHENE FILM MARKETNEW PRODUCT LAUNCH

Highly flat monolayer graphene is the new product launched by Graphenea. On a 2" sapphire substrate, a copper thin film is created with CVD to produce graphene. This novel product is intended for use in photonics, high-performance electronics, magnetic memory, and freestanding membranes and has a very low roughness of less than 4 nm.

The product's goal is to fulfil the demands for wafer-scale integration necessary to construct homogeneous graphene devices in a way that is compatible with the most recent techniques used in the manufacturing industry.

Due to the sapphire substrate's ability to tolerate mechanical damage and its ability to prevent tearing and creasing of the thin Cu sheet, the flat graphene result is prepared for electrochemical delamination or dry techniques of transfer.The wafer is 430 micrometres thick overall. The internet store provides comprehensive product information.

The 25 workers of Graphenea work to support their customers' successful development of graphene applications across a variety of industries and in more than 60 different nations.

Their offering, which consists of CVD graphene films, Graphene Field-Effect-Transistors chips (GFETs), Graphene Foundry Services (GFAB), and Graphene Oxides, supports their customers through research and innovation. Facilities for Graphenea can be found in Boston, Massachusetts, and San Sebastián, Spain.
