A Semi-Flex PCB (Printed Circuit Board) is a form of flexible printed circuit board that provides both flexibility and rigidity on the same board. It is intended to provide some flexibility while keeping some structural integrity or stiffness, making it appropriate for applications that require both bending capabilities and a certain level of stability.
Semi-Flex PCBs are frequently utilized in devices and systems where space is limited or distinctive form factors are required. Semi-flex PCBs frequently include stiffeners or rigid portions in parts of the board where components or connectors are installed.
These stiffeners increase the rigidity of particular locations, ensuring proper alignment and mechanical stability. Semi-Flex PCBs are built using layer stackup designs that blend flexible and rigid layers.
Semi-Flex PCBs are utilized in a variety of applications where the PCB must fit into a tight space or conform to a certain shape while maintaining structural integrity.
Compact electronic gadgets, medical devices, automobile electronics, and aeronautical systems are among examples. Semi-Flex PCBs can be made in complex shapes to meet the needs of the device into which they will be integrated.
This feature assists designers in optimizing space consumption and component arrangement. Semi-Flex PCBs bridge the gap between fully flexible and stiff PCBs by balancing mechanical flexibility with structural integrity.
They are used in particular applications when both features are required for proper functionality and design optimization. Semi-Flex PCBs can be utilized in places where typical stiff PCBs may not be suitable.
The Global Semi-Flex PCB market accounted for $XX Billion in 2022 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2024 to 2030.
The Semi-Flex PCB technical definition was grouped by ICAPE. It has two layers at the bending zone and up to 16 layers overall. The rigid PCB with deep control milling to assume a bending zone (max 2 layers) is a technological highlight.
economical choice for a static and adaptable application. Base Copper is one of the ingredients of FR4. It is 1 Oz thick in the bending zone and 1/2 Oz thick at the base. stiff zonz up to 3+C53 Oz.
Track and spacing must be at least 0.075mm apart. Available surface treatments include soft-Gold, Gold finger, immersion Tin, and immersion Silver. PCB thickness should be between 1,00 and 2,4mm with a minimum mechanical drill of 0.15mm.
