A single-phase energy metering IC is a specialized electronic component developed for measuring and monitoring electrical energy usage in single-phase power systems. It is typically utilized in home and small business applications using a single phase power supply.
Various functionalities necessary for reliable energy measurement, including as voltage and current sensing, signal processing, analog-to-digital conversion, and data transfer interfaces, are often included into the energy metering IC.
It is in charge of properly measuring the active power, reactive power, apparent power, and energy consumption of the linked electrical load.
Single-phase energy metering integrated circuits (ICs) are critical for precise energy measurement and management in single-phase power systems. They are frequently utilized in applications such as power invoicing, load monitoring, and energy saving.
The selection of an IC is influenced by criteria like as measurement precision, communication interfaces, cost, and application-specific characteristics. A single-phase energy metering IC’s principal role is to transform electrical characteristics such as voltage and current into digital data that can be processed and utilized for energy monitoring.
These integrated circuits (ICs) are often outfitted with analog-to-digital converters (ADCs), which transform analogue data from current and voltage sensors into digital values.
The Global Single-Phase Energy Metering IC market accounted for $XX Billion in 2023 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2024 to 2030.
A Single Phase Energy Meter IC with Self-Calibration to Reduce Time to Market.
The ADE9153A is a high-precision energy metering integrated circuit with the m Sure® self-calibration capability. When a shunt resistor is employed as a current sensor, m Sure allows meters to automatically calibrate current and voltage channels without the usage of external calibrated sources or reference meters.
Class 1 and Class 2 meters are supported by m Sure self-calibration.
ADE9x Energy Metering ICs accurately monitor active energy (kWh), apparent energy (kVA), reactive energy (kVAR), rms, and power quality.
IDT Energy Metering IC Selected by Sanxing for Single Phase Smart Energy Meter. Ningbo Sanxing Electric Co., Ltd., a leading manufacturer of electricity meters, has chosen the IDT single-phase energy metering IC for use in its single-phase smart energy meter, according to a recent announcement from Integrated Device Technology, Inc., the Analogue and Digital Company providing essential mixed-signal semiconductor solutions.
The IDT energy metering IC was chosen by Sanxing because it has the greatest dynamic range of all the high-accuracy products available. The IDT90E24 is part of a series of high-performance energy metering integrated circuits (ICs) for single-phase two-wire, single-phase three-wire, or electricity meters with anti-tampering mode.
It has the industry’s greatest dynamic range of 5000:1, allowing precise measurement of tens of kilowatts down to a few watts. The gadget is perfect for monitoring huge quantities of power consumption during peak load hours, as well as modest amounts of electricity generated from renewable sources such as solar and wind during off-peak hours; all inside a single smart energy meter.
The recently announced IDT90E24 product from IDT has a broad dynamic range, making it appropriate for applications that need a broad metering range. It was successful in all of Sanxing’s internal testing and received praise from its customers.
Products have the greatest dynamic range in the market and the highest accuracy, making it easier for the customers to integrate several energy metering devices into a single, functional solution.
Because of the streamlined design and production procedure, our clients may complete all necessary tests faster. The business will keep providing total smart metering solutions that are advantageous for utilities and meter makers in terms of cost and environmental impact.
The IDT90E2x is available in a Pb-free 28-lead SSOP package and is meant to be long-lastingly stable regardless of changes in the surrounding environment and grid conditions. The gadget completely complies with the requirements of IEC 62052-11, IEC 62053-21, and IEC 62053-23 for class 1 or class 2 single-phase watt-hour meters or class 2 single-phase var-hour meters.
