A TMR element’s magnetic structure is quite similar to a GMR element’s. The current, however, flows horizontally to the film surface in a GMR element as opposed to perpendicularly in a TMR element.
A TMR element is a thin-film element created utilizing cutting-edge thin-film processing technology that has a barrier layer comprised of a thin insulator of 1 to 2 nm sandwiched between two ferromagnetic layers (free layer/pin layer).
While the magnetization direction of the pin layer is fixed, the direction of the free layer’s magnetization varies depending on the direction of the external magnetic field. Along with this shift in the free layer, the electrical resistance of the TMR element also varies.
The Global TMR sensors market accounted for $XX Billion in 2023 and is anticipated to reach $XX Billion by 2030, registering a CAGR of XX% from 2024 to 2030.
The “S-5701 B Series” surface mount TMR (Tunnel Magneto Resistance) sensor IC was introduced by ABLIC Inc. It is a magnetic sensor with super-low current consumption, great magnetic sensitivity, long life, and an operational current consumption of under 160nA.
However, it differs from other MR sensor ICs like Anisotropic Magneto Resistive (AMR) or Giant Magneto Resistive (GMR) sensor ICs in that it has a high sensitivity and an exceptionally low current consumption (160nA), making it a cutting-edge product that addresses the drawbacks of a traditional reed switch.
ABLIC has now launched a new product, the “S-5701 B Series,” a TMR sensor IC in a “Small, Smart and Simple” product lineup that detects horizontal magnetic fields allowing users to significantly extend client base
The TMR sensors from TDK are a brand-new class of magnetic sensors that make use of a TMR element, a very sensitive HDD head replicating component. The magnetoresistance effect, which describes a change in resistance brought on by the application of an external magnetic field, serves as the foundation for the reading components of HDD heads.
A33110 and A33115 magnetic position sensors have been released by Allegro Micro Systems, Inc., a market leader in sensing and power solutions for motion control and energy-efficient systems.
Allegro’s newest sensors combine vertical Hall technology (VHT) from the company with cutting-edge tunneling magnetoresistance (TMR) technology in a single sensor package. They are intended for advanced driver assistance systems (ADAS) applications that demand high levels of accuracy and heterogeneous signal redundancy.
These revolutionary angle sensors are the first of their type to include both of these technologies into a single unit. This VHT + TMR offering is an excellent heterogeneous redundant sensor solution and a crucial step in delivering the dependability necessary for high degrees of automated driving.
Murata Manufacturing Co., Ltd has entered into a sales agreement with Crocus Technology for the exclusive right to sell select Crocus TMR sensor products in Japan, China, Taiwan and Korea , and the non-exclusive right to sell the Products worldwide outside the Territory.
With the help of monolithic technology, the magnetic sensor in Crocus’ TMR sensor products is completely integrated on top of a proprietary CMOS lithography process, simplifying the manufacturing process and achieving higher levels of integration and performance metrics.
Crocus TMR sensors have high sensitivity and low noise plus nano-level low power consumption and offer high reliability and stable magnetic performance over temperature and outstanding robustness under extreme operating environments.
